GN 131.1

Two-Way Linear Actuator Connectors

for linear actuators Ø18, for single axis system

GN 131.1

Two-Way Linear Actuator Connectors
Linear actuator connectors

GN 131.1-AL

Two-Way Linear Actuator Connectors
Aluminum

GN 131.1-NI

Two-Way Linear Actuator Connectors
Stainless Steel-Linear actuator connectors

GN 131.1

Two-Way Linear Actuator Connectors
Linear actuator connectors

Identification No.

No. 2: with 2 Stainless Steel-Clamping screws DIN 912

Version in Aluminium

plastic coated

black, RAL 9005, textured finish SW

Version in Stainless Steel AISI CF-8 NI

  • matt shot-blasted
  • Bore only with slide bushing (G18)

Clamping bores mechanically machined

Slide bushing

Polyamide

Socket cap screw DIN 912

Stainless Steel AISI 304

Hexagon nuts DIN 985

Stainless Steel AISI 304

GN 131.1 linear actuator connectors are normally supplied mounted only in connection with a linear actuator and for function control.

By means of the clamping screws on the guide bores d1 / d2 the movement can either be set or the linear actuator connector can be clamped (after setting of final adjustment).

The standard version of the clamping screws are socket cap screws with hexagonal socket DIN 912. They can be replaced by adjustable clamping levers  GN 911 (see table of dimensions).
